YTO Tractor X1204
The YTO-X1204 tractor is developed on the basis of the Italian wheeled tractor chassis technology, adopting the British technology-based 6-cylinder turbocharged engine. The machine body has a streamline configuration. It is low in specific fuel consumption and better in power economic efficiency. It has multiple gears and a wide speed range. Besides, it is flexible in steering and easy to operate.

YTO X1204 Tractor Technical Specification


YTO Tractor Model: YTO-X1204
Type: 4X4
Overall Dimensons (L X W X H) (mm) :  5000 X 2330 X 2960mm
WheelBase (mm): 2688.5mm
Min. Ground Clearance (mm): 470 mm
Min. Operating Mass (kg):  4850 kgs
Tyre Spec. front/rea: 14.9-26 / 18.4-38
Wheel Tread , front / rear: 1672-2003 / 1662-2262
Gear Shift, forward/Backward: 12/4
Speed Range (Km/H), forward/backward : 2.34-30.55 / 5.04-14.27
PTO Power (Kw): 71.25
Lifting Force (KN): 28

Diesel Engine
Model: LR6B5-23
Type: Six Cylinder, vertical, water cooled, four stroke, direct injection, turbocharged
Displacement (L): 7.43
Rated Power / Speed (Kw) / (r/min) : 88.2 / 2400

Contact us for all your YTO tractor,YTO machinery and YTO spare parts requirement.
